File

projects/UILibrary/src/app/models/uilibrary.model.ts

Description

This interface contains key value pairs, some custom operation which generates display key and display value. Also it includes custom operation handler for click event on properties.

Index

Properties

Properties

customOperations
customOperations: IEventHandler
Type : IEventHandler
Optional

Click event handler for property.

displayKey
displayKey: string
Type : string
Optional

KEY value to be displayed on component.

displayValue
displayValue: any
Type : any
Optional

VALUE to be displayed on component.

displayValueType
displayValueType: ValueType
Type : ValueType
propertyMetadata
propertyMetadata: IMetadata[]
Type : IMetadata[]
Optional
visible
visible: boolean
Type : boolean

This flag decides if PROPERTY will be displayed on component or not.

import { IChatSettings } from './chat.settings';
import { IChatMessage } from './chat.message';

export * from './chat.message';
export * from './chat.settings';

/**
 * It is collection of Interaction which need to be displayed on scenario component.
 */
export interface IScenario {
  interactions: IInteraction[];
}

export interface IInteraction {
  /**
   * Unique id for the interaction.
   * Note: this interactionId is also used to provide id for the div element.
   */
  interactionId: string;
  properties?: Property[];
  associatedData?: Property[];
  startTime: number;
  displayCallTimer: boolean;
  /**
   * parties is supposed to contain data about all the participants in call except agent himself.
   */
  parties?: IParty[];
  /**
   * Operations/buttons which needs to be displayed in interaction and its handlers.
   */
  operations?: IOperation[];

  /**
   * It contains URLs for minimize, maximize, interaction specific icon urls for interaction.
   * And header number which needs to be displayed at top.
   */
  UIHeadersData: IInteractionUIHeaders;

  /**
   * Should contain identifying information about the main party in the interaction.
   */
  subheaderData: IPartyHeader;

  /**
   * This enables and configures the chat UI
   */
  chat?: {
    settings: IChatSettings;
    messages: IChatMessage[];
    isCustomerTyping?: boolean;
  };
}

export interface IActivity {
  interactionId: string;
  WhoObject: IActivityDetails;
  WhatObject: IActivityDetails;
  whoList: IActivityDetails[];
  whatList: IActivityDetails[];
  CallType: string;
  CallDurationInSeconds: string;
  Subject: string;
  SubjectFieldName: string;
  NameFieldName: string;
  RelatedToFieldName: string;
  Description: string;
  Status: string;
  ActivityDate: string;
  TimeStamp: Date;
  ActivityId: string;
  quickCommentList: string[];
}

export interface IActivityDetails  {
  objectType: string;
  displayName: string;
  objectName: string;
  objectId: string;
  url: string;
}

/**
 * This contains the main identifying information about the interaction.
 */
export interface IPartyHeader {
  /**
   * Image that identifies the type of interaction
   * or the type of the identifying information(ex: phone icon for phone number)
   */
  image?: URL;
  /**
   * The tooltip to be displayed when the image is hovered over
   */
  tooltip?: string;
  /**
   * The value to be displayed
   */
  value: string;
}

/**
 * It contains URLs for minimize, maximize, interaction specific icon urls for interaction.
 * And header number which needs to be displayed at top.
 */
export interface IInteractionUIHeaders {
  /**
   * Minimize icon url.
   */
  minimizeUrl: URL;

  /**
   * Maximize Icon url.
   */
  maximizeUrl: URL;

  /**
   * This is the URL for the status image.
   * @memberof IInteractionUIHeaders
   */
  statusUrl: URL;

  /**
   * This is the handler for focus(Triggered on click of status).
   * @memberof IInteractionUIHeaders
   */
  focusHandler?: IFocus;

  /**
   * This is the text which is going to be displayed for status of the call.
   *
   * @memberof IInteractionUIHeaders
   */
  statusText: string;

  /**
   *This member will contain the text related to the direction of the call. E.g Inbound, Outbound etc.
   * @memberof IInteractionUIHeaders
   */
  directionText: string;

  /**
   *This data will be used to display hold counter whihc will be the combination of the current hold time and complete hold time.
   * @memberof IInteractionUIHeaders
   */
  holdCounterData?: IHoldCounterData;

  /**
   *If this value is set to true then hold counter is displayed based on the holdCounterData.
   * @memberof IInteractionUIHeaders
   */
  displayHoldCounter: boolean;
}
export interface ICallDuration {
  startTime: number;
  endTime: number;
}
export interface IHoldCounterData {
  pastCallDurations?: ICallDuration[];
  currentHoldStartTime: number;
}

/**
 * It contains Operation Icon URL and its hadlers which need to be displayed in Interaction.
 */
export interface IFocus {
  /**
   * metadata related to operation.
   */
  operationMetadata?: IMetadata[];
  /**
   * name of the operation.
   */
  operationName: string;
  /**
   * Handler which needs to be invoked when someone clicks on the operation icon.
   */
  handler: (operationName: string, operationMetadata?: IMetadata[]) => void;
}

/**
 * It contains Operation Icon URL and its hadlers which need to be displayed in Interaction.
 */
export interface IOperation {
  /**
   * metadata related to operation.
   */
  operationMetadata?: IMetadata[];
  /**
   * name of the operation.
   */
  operationName: string;
  /**
   * URL for the icon of operations.
   */
  icon: URL;
  /**
   * Title which needs to be doisplayed when someone hovers over the icon.
   */
  title: string;
  /**
   * Handler which needs to be invoked when someone clicks on the operation icon.
   */
  handler: (operationName: string, operationMetadata?: IMetadata[]) => void;
  /**
   * Browser accesskey to jump instantly to this operation Should conform to AMC norms and consist of a single printable character.
   */
  accesskey?: string
}

/**
 * This contains properties and operations to be displayed for conference member.
 */
export interface IParty {
  header: IPartyHeader;
  properties: Property[];
  operations: IOperation[];
}

/**
 * key value pairs which can be used amongst other interfaces/classes to store metadata of those entities.
 */

export interface IMetadata {
  key: string;
  value: string;
}

/**
 * This interface contains key value pairs, some custom operation which generates display key and display value.
 * Also it includes custom operation handler for click event on properties.
 */
export interface IProperty {
  /**
   * KEY value to be displayed on component.
   */
  displayKey?: string;

  /**
   * VALUE to be displayed on component.
   */
  displayValue?: any;
  displayValueType: ValueType;
  propertyMetadata?: IMetadata[];

  /**
   * Click event handler for property.
   */
  customOperations?: IEventHandler;
  /**
   * This flag decides if PROPERTY will be displayed on component or not.
   */
  visible: boolean;
}

/**
 * A helper method to make instances of [IProperty]
 */
export class Property implements IProperty {
  private key: string;
  private value: any;
  /**
   * KEY value to be displayed on component.
   */
  displayKey?: string;

  /**
   * VALUE to be displayed on component.
   */
  displayValue?: any;
  displayValueType: ValueType;
  propertyMetadata?: IMetadata[];

  /**
   * Click event handler for property.
   */
  customOperations?: IEventHandler;
  /**
   * This flag decides if PROPERTY will be displayed on component or not.
   */
  visible: boolean;

  /**
   * Operation responsible for generating displayKey and dispkayValur from key and value.
   */
  displayOperation: () => void = () => {
    this.displayKey = this.key;
    this.displayValue = this.value;
  }

  /**
   *
   * @param key
   * @param value : if value type is COUNTER then value should be start time in MilliSeconds.
   * @param visible
   * @param valueType
   * @param customOperation
   */
  constructor(
    key: string,
    value: any,
    visible?: boolean,
    valueType?: ValueType,
    customOperation?: IEventHandler
  ) {
    this.key = key;
    this.value = value;
    visible != null ? (this.visible = visible) : (this.visible = true);
    valueType != null
      ? (this.displayValueType = valueType)
      : (this.displayValueType = ValueType.STRING);
    this.customOperations = customOperation;
    this.displayOperation();
  }
}

/**
 * Interface which contains eventName and handler associated with it.
 */
export interface IEventHandler {
  eventName: string;
  handler: (eventName: string, eventMetadata?: IMetadata[]) => void;
  eventMetadata?: IMetadata[];
}

/**
 * enum for Value types of PROPERTY.
 */
export enum ValueType {
  STRING,
  COUNTER
}
